UV Resin KS408A

UV Resin KS408A

KS408A UV Resin is a precise and durable ABS-like resin for industrial SLA 3D printer. It is an ideal 3D printing material with perfect smoothness and details.

Product Details

KS408A UV Resin is a precision and durable ABS-like lithography resin used in SLA 3D printers. It is a master model for the production of common 3D printing materials, automotive, medical, consumer electronics and other industrial fields, conceptual models, general components,functional components can be produced.The parts durability building with KS408A is over 6.5months.Get more details about the 3D Printer Resin Cost.


TYPICAL FEATURES


-The medium viscosity of the liquid resin makes the re-coating as well as the machine and parts cleaning easier

-Improved strength and dimension retention in humid condition

-Need minimal part finishing

-Long shelf life in machine



TYPICAL BENEFITS


-Need less part finishing time, easier post-curing

-Building accurate and high tough parts with an improved dimensional stability

-High quality controls for vacuum casting parts

-Low shrink and good resistance to yellowing

-Magnificent white color

-Outstanding machinable SLA material


3D Printer Resin Cost


3D Printer Resin Cost

 3D Printer Resin Cost


Physical Properties of Liquid Material

Appearance

Opaque White

Density

1.11-1.14g/cm³ @ 25 ℃

Viscosity

355-455 cps @ 28 ℃

Dp

0.135-0.155 mm

Ec

9-12 mJ/c㎡

Building layer thickness

0.05-0.15mm


Mechanical Properties of Post-Cured Material


MEASUREMENT

TEST METHOD

VALUE



90-minute UV post-cure

Hardness , Shore D

ASTM D 2240

76-82

Flexural modulus, Mpa

ASTM D 790

2,690-2,775

Flexural strength, Mpa

ASTM D 790

68- 75

Tensile modulus, MPa

ASTM D 638

2,180-2,395

Tensile strength, MPa

ASTM D 638

27-31

Elongation at break

ASTM D 638

12 -20%

Impact strength, notched lzod, J/m

ASTM D 256

58 - 70

Heat deflection temperature, ℃

ASTM D 648 @66PSI

55-65

Glass transition, Tg,℃

DMA,E”peak

55-70

Coefficient of thermal expansion, /℃

TMA(T<Tg)

97*E-6

Density, g/cm3


1.14-1.16


Note: The temperature for JS-UV-2016 resin processing and storage should be lower than 25℃, and the temperature recommended is 18℃ - 25℃.
