KS06FR
KS06FR is an ABS-like SLA resin featuring flame resistance, high accuracy, and durability. Designed for solid-state SLA platforms, it is suitable for master patterns, concept models, general parts, and functional prototypes across automotive, medical, and consumer electronics industries.
TECHNICAL DATASHEET
PRODUCT DESCRIPTION
KS06FR is an ABS-like SLA resin featuring flame resistance, high accuracy, and durability. Designed for solid-state SLA platforms, it is suitable for master patterns, concept models, general parts, and functional prototypes across automotive, medical, and consumer electronics industries.
ADVANTAGES
> Medium Viscosity Resin Allows for Easy Recoating and Cleaning
> Improved Strength and Dimensional Stability in Humid Environments
> Requires Minimal Finishing and Post-curing Time
> Excellent Machinability and Low Shrinkage
> V0-Level Flame Retardant With Good Yellowing Resistance
IDEAL APPLICATIONS
> Functional Prototypes
> Flame-Retardant End-Use Parts
> Precision Industrial Components
> SLA Parts Requiring High Strength and Details
> Components Used in Humid or Demanding Environments
TECHNICAL DATASHEET
Physical Properties - Liquid Material
Appearance
| Greenyellow
| Dp | 0.135-0.155mm
|
Viscosity
| 1.2-1.24g/cm³ @ 25 ℃ | Building Layer Thickness | 9-12 mJ/cm² |
| Density | 150-500 cps @ 25 ℃ | Ec
| 0.05-0.12mm |
Mechanical Properties of Post-Cured Material
MEASUREMENT
| TEST METHOD | VALUE (UV Curing and Thermocuring) |
| Hardness, Shore D | ASTM D 2240 | 76-82
|
| Flexural Modulus, Mpa | ASTM D 790 | 2,650-2,750
|
| Flexural Strength, Mpa | ASTM D 790 | 80-90 |
| Tensile Modulus, MPa | ASTM D 638 | 2,150-2,370 |
| Tensile Strength, MPa | ASTM D 638 | 33-38 |
| Elongation at Break | ASTM D 638 | 12%-18% |
| Impact strength, notched lzod, J/m | ASTM D 256 | 58-70 |
| Heat deflection temperature, ℃ | ASTM D 648 @66PSI | 48-52 |
| Glass transition, Tg , ℃ | DMA，E" Peak | 50-54
|
| Density, g/cm³ |
| 1.25-1.3
|
