TECHNICAL DATASHEET
PRODUCT DESCRIPTION
Kings SLM 3D Print Material Copper-tin Alloy CuSn10 is a Copper-tin alloy with high elongation and medium hardness suits for a wide range of industrial applications.
TYPICAL FEATURES
> Resistance to cavitation in sea water
> Excellent abrasion performance
> Good thermal conductivity
> Non-magnetic
> Good corrosion resistance
Ideal Applications
> Parts and housings for maritime applications
> Bushings, Bearings
> Heat Exchangers
> Copper Shields
Technical Datasheet
General Properties | Density ISO3369 | ≥8.78 g/cm3 |
Mechanical Properties (As-built) | Tensile Strength ISO6892-1 | ≥540 MPa |
Yield Strength ISO6892-1 | ≥400 MPa |
Elongation after Fracture ISO6892-1 | ≥20 % |
Vickers hardness ISO6507-1 | ≥115 HV5/15 |
Hardness (HRC) ISO6507-1 | 147 |
Thermal conductivity at 20 ºC | 59W/mK |
Surface roughness Ra X, Y | 9μm |
Surface roughness Ra Z | 10μm -26 μm |
Mechanical Properties (Heat treated) | Tensile Strength ISO6892-1 | N/A |
Yield Strength ISO6892-1 | N/A |
Elongation after Fracture ISO6892-1 | N/A |
Vickers hardness ISO6507-1 | N/A |
