TECHNICAL DATASHEET
PRODUCT DESCRIPTION
KS85HT is a high-performance, ABS-like SLA resin featuring excellent precision and high-temperature resistance. With a vibrant green appearance and medium viscosity, it offers smooth coating, easy post-processing, and is ideal for demanding prototyping applications.
ADVANTAGES
> Fast Printing Speed
> Excellent High-temperature Resistance and Durability
> Excellent Processability and Toughness
> Only Minimal Component Modification Is Required
IDEAL APPLICATIONS
> Dental
> Toys
> Molds
> Automotive
> Aerospace
> Concept Models
>General Parts
TECHNICAL DATASHEET
Physical Properties - Liquid Material
Appearance
| Green | Dp | 0.135-0.155mm |
| Viscosity | 360-400cps@25℃ | Building Layer Thickness | 0.05-0.12mm |
Density
| 1.11-1.14g/cm3@25℃ | Ec | 9-12mJ/c㎡ |
Mechanical Properties of Post-Cured Material
| Hardness Shore D | 78-82
|
| Flexural Modulus, Mpa | 2650-2750 |
| Flexural Strength, Mpa | 60-75 |
| Tensile Modulus, MPa | 2150-2370 |
| Tensile Strength, MPa | 25-30 |
| Elongation at Break | 12-17% |
| Impact Strength Notched Izod, J/m | 55-65 |
| Heat Deflection Temperature, ℃ | 75-85 |
| Glass Transition Temperature, ℃ | 74-80 |
| Density, g/cm³@ 25℃ | 1.11-1.14 |
Note: Recommended temperature for processing and storage of the above resin should be 18℃-25℃.
