TECHNICAL DATASHEET
PRODUCT DESCRIPTION
SLM 3D Print Material CoCr is Cobalt, chromium, and molybdenum alloy designated for medical, denture and high-temperature applications.
TYPICAL FEATURES
> Great as-finished surface
> High toughness
> High strength
> Excellent bio-compatibility
> Good corrosion resistance
Ideal Applications
> Medical implants
> High temperature
> High-performance engineering
Technical Datasheet
General Properties | Density ISO3369 | ≥8 35g/cm³ |
Mechanical Properties (As-built) | Tensile Strength ISO6892-1 | ≥1060 MPa |
Yield Strength ISO6892-1 | ≥800 MPa |
Elongation after Fracture ISO6892-1 | ≥8 % |
Vickers hardness ISO6507-1 | N/A |
Hardness (HRC) ISO6507-1 | 36-38 |
Thermal conductivity at 20 ºC | 13 W/mK |
Surface roughness Ra X, Y | 4 μm |
Surface roughness Ra Z | 8 μm-12 μm |
Mechanical Properties (Heat treated) | Tensile Strength ISO6892-1 | ≥970 MPa |
Yield Strength ISO6892-1 | ≥620 MPa |
Elongation after Fracture ISO6892-1 | ≥12% |
Vickers hardness ISO6507-1 | ≥310 HV5/15 |
