SPECIFICATIONS OF KINGS-1700 INDUSTRIAL SLA 3D LASER PRINTER
Basic information
Construction Size: 1700mm(X)×800mm(Y)×600mm(Z)
Equipment Size (without display): 247cm(W)*168cm(D)*230cm(H)
Equipment Weight:about 3600kg
Rated Dissipation: 2.2KVA
LASER SYSTEM
Laser Type: Nd: YV04 Solid Laser
Wave Length: 355nm
Power: Minimum Power to Liquid Level≥300mW
COATING SYSTEM
Coating ModeIntelligent Position Vacuum Recoating
Normal Layered Thickness: 0.1mm
Rapid Build Layered Thickness: 0.15mm
Precise Build Layered Thickness: 0.05mm
Special Build Layered Thickness: 0.05mm~0.20mm
OPTICAL & SCANNING SYSTEM
Light Spot(diameter @1/e2): 0.10-0.15mm
Scanning Mode: Germanic Galvanometer Scanner
Parts Scanning Speed: Maximum 18.0m/s
ELEVATOR SYSTEM
Vertical Resolution Ratio: 0.0005mm
Repeat Positioning Accuracy: ±0.01mm
RESIN TANK
First Tank Weight: 1300kg
Forming Material: Photosensitive Resin
Resin Heating Method: Bottom Heating with Silicone Rubber
CONTROL SOFTWARE
Machine Control Software: KING3D Control Software
Device Software Interface: 3D Design Software, STL File Format
SOFTWARE SYSTEM
Master Controller Operation System: Windows 7/10
Network Type and Protocol: Ethernet, TCP/IP
INSTALLATION CONDITION
Current Source: 200-240VAC 50/60Hz, Single Phase,10A
Ambient Temperature: 20-26ºC
Relative Humidity: ＜40%，Frost Free Knot
Kings Industrial SLA 3D Printer, a large commercial 3D printer, ideal for rapid prototyping equipment，China's best 3D printer manufacturer。
We specializes in industrial grade SLA 3D printers. Our SLA printers are suitable for rapid prototype and molds in many industries including automobile, footwear,aerospce,arts&crats, consumer products and etc. Kings1700 Pro SLA 3D printers can help you reduce the cost of prototype, and achieve unprecedented improvements in accuracy, speed, surface quality, material types, reliability and stability.
Kings1700 Pro brings the principle of SLA light curing technology into full play. It has super-fast printing speed max.18m/s. The printed model of the hand plate can be used for product development, rapid tooling manufacturing and final use.
Kings1700 Pro adopts high precision galvanometer scanning system and intelligent positioning vacuum adsorption coating system. The thickness of the coating can be accurate to 0.05 mm.
It can print a variety of properties of photosensitive resins, including hard materials, soft materials, elastic materials, color materials, transparent materials, high temperature resistant materials, high strength materials. The products made of these materials not only have precise details and excellent mechanical properties, but also cost much less than CNC process and other 3D printing technologies.
Kings industrial grade 3D printer is a well-known domestic brand manufacturer. Kings1700 Pro belongs to SLA light-cured 3D printer. It has the characteristics of high accuracy, rapidity and good stability.
It can be used to produce models, handicraft, icon, animation and other products.
