Shoe mold 3D printer plays an important role in the shoe market. 3D printing shoes with original design and insoles can be used for fast prototype production and trying new manufacturing processes.
Shoe mold 3D printer features
High-quality components, fine workmanship
Made by high-quality welding square tube and marble, shoe mold 3D printer has the best stability and can ensure accuracy and durability.
The best choice for material development
It is very suitable for the use of the research and development and research of resin materials. The compact large barrel makes the material supplement and convenient.
Wide material selection
Selected a variety of different custom design printing materials, which have unique features suitable for functional prototypes and small batch manufacturing.
Custom tailored
We provide a lot of customized options for free. The available upgrades include autofocus, automatic material reinfting, environmental sensor, and remote diagnosis and control to ensure that you prepare for the industry.
Compact and economical
Our most affordable SLA shoe mold 3D printer, the construction size is 300 mm x 600 mm x 350 mm, respectively. These compact sizes are very suitable for printing shoes, medical, sculpture, toys and jewelry manufacturing industries, as well as small-size models used by scientific research institutions.
If you are considering to buy shoe mold 3D printer from trusted supplier, welcome to contact us for detailed information!
| BASIC INFORMATION |
| Max Printing Size | 350*600*350mm |
| Machine Size | 108cm(W)*95cm(D)*198cm(H) |
| Rated Power Consumption | 1.5KVA |
| Machine Weight | About 880kg |
| LASER SYSTEM |
|
| Laser Type | Solid-state frequency tripled Nd: YV04 |
| Wavelength | 355nm |
| Power | Resin Surface Power≥ 300 mW |
| OPTICAL & SCANNING SYSTEM |
| Scanning Mode | Germanic galvanometer scanner |
| Variable Beam System | Galvo/Closed-loop |
| Beam Size (diameter @1/e2) | 0.075-0.8mm(Variable Beam) |
| Max Scanning Speed | 15.0m/s |
| RECOATING SYSTEM |
| Main Sturcture | Marble recoater frame, marble elevator holder and marble scanning system base |
| Coating Mode | Intelligent position vacuum recoating |
| Vertical Resolution Ratio | 0.0005mm |
| Repeat Positioning Accuracy | ±0.01mm |
| Layer Thickness | 0.05mm~0.25mm |
| Accuracy | L≤150mm, ±0.1mm;
L＞150mm, ±0.1%*L |
| CONTROL SOFTWARE |
| Motion Control System | Closed-loop |
| Machine Control Software | KINGS 3D control software |
| Input Data File Format | STL/SLC |
| Operating System | Windows 7/10 |
| Network Type and Protocol | Ethernet，TCP/IP |
| INSTALLATION CONDITION |
| Electrical Requirement | 200-240VAC 50/60Hz, single-phase,10A |
| Ambient Temperature | 20-26ºC (72-79℉) |
| Relative Humidity | ＜40%，non-condensing |
| First Tank Resin | About 140kg |
| WARRANTY |
| Machine | Two years |
| Laser | Two years |
